Xyoo 2025, kev lag luam thoob ntiaj teb tau hloov pauv. Txawm koj tsim cov hniav cua turbine, cov khoom siv tsheb, lossis FRP (Fiber Reinforced Polymer) cov kav dej, qhov kev ntseeg tau ntawm kojfiberglass roving neeg muag khoomtsis yog tsuas yog ib qho kev yuav khoom xwb - nws yog lub hauv paus tseem ceeb ntawm kev lag luam.
Thaum qhov ceev ntawm kev tsim khoom nce ntxiv thiab qhov zoo ntawm kev kam rau siab zuj zus, tsuas yog yuav qhov roving "pheej yig tshaj plaws" tuaj yeem ua rau muaj kev puas tsuaj loj heev, cov khoom pov tseg ntau, thiab cov tshuab puas tsuaj. Txhawm rau kom koj txoj saw hlau ruaj ntseg, ntawm no yog xya yam tseem ceeb uas koj yuav tsum soj ntsuam thaum tshuaj xyuas tus khub koom tes.
1. Kev Siv Tshuaj Lom Zem thiab Kev Sib Piv ntawm Cov Resin
Qhov "sizing" (cov tshuaj pleev xim rau ntawm cov iav fiber) yog qhov tseem ceeb tshaj plaws ntawm kev siv tshuabfiberglass rovingNws ua haujlwm ua tus choj tshuaj ntawm cov iav inorganic thiab cov organic resin.
Qhov Kev Pheej Hmoo:Siv cov khoom roving nrog qhov loj me uas tau kho kom zoo rau Polyester hauv lub kaw lus Epoxy resin yuav ua rau "wet-out" tsis zoo thiab lub zog interlaminar shear tsis muaj zog.
Kev Ntsuam Xyuas:Tus neeg muag khoom puas muaj cov qhov loj me tshwj xeeb rau koj cov txheej txheem tshwj xeeb (piv txwv li, Silane-based rau thermoplastics vs. starch-based rau cov ntaub siv tshwj xeeb)? Nug txogcov qauv sib xwsthiab cov txiaj ntsig ntawm kev sim nqus cov resin.
2. Kev sib xws ntawm Tex thiab Filament Diameter
Hauv cov txheej txheem ceev ceev xws likev sib txhuamlos yogkev sib txuas ntawm cov xov hlau, kev sib xws yog tus huab tais. Yog tias Tex (linear density) hloov pauv ntau heev, koj cov khoom kawg qhov sib piv ntawm iav thiab resin yuav hloov pauv, ua rau muaj qhov tsis muaj zog ntawm cov qauv.
Fuzz thiab tawg:Cov neeg xa khoom tsis zoo feem ntau muaj cov filaments tawg uas sib sau ua ke hauv koj cov lus qhia thiab cov tensioners. Qhov no ua rau lub sijhawm tsis ua haujlwm ntau zaus thiab ua rau lub reinforcement tsis muaj zog.
Cov Lus Qhia Txog Kev Tshuaj Xyuas:Thov tus neeg muag khoomCPK (Cov Txheej Txheem Muaj Peev Xwm)cov ntaub ntawv rau Tex kev sib xws dhau 12 lub hlis.
3. Muaj Peev Xwm Tsim Khoom thiab Kev Nthuav Dav
Ib tug neeg muag khoom uas zoo rau kev txiav txim 5-tuj yuav ua tsis tau raws li koj daim ntawv cog lus 500-tuj. Nyob rau hauv lub ntiaj teb tam sim no,kev ruaj khov ntawm cov khoom xa tuajyog qhov tseem ceeb tshaj plaws.
Ntim:Puas yog lub chaw tsim khoom muaj ntau lub cub tawg? Yog tias muaj ib lub cub tawg raug kho, lawv puas tuaj yeem hloov cov khoom mus rau lwm kab yam tsis ncua koj cov khoom xa tuaj?
Lub Sijhawm Ua Tau:Ib tus khub koom tes txhim khu kev qha yuav tsum muab cov sijhawm ua tiav meej, muaj cov ntaub ntawv pov thawj thiab muaj lub network logistics uas muaj peev xwm daws teeb meem kev thauj khoom thoob ntiaj teb.
Kev Tshuaj Xyuas Sib Piv: Dab Tsi Sib Txawv Tus Khub Sib Koom Tes?
Yuav pab koj pab neeg yuav khoom txiav txim siab sai dua, siv lub rooj hauv qab no los qhia qhov txawv ntawm tus khub koom tes zoo thiab tus muag khoom yooj yim.
Daim Ntawv Teev Xyuas Kev Ntsuam Xyuas Tus Neeg Muab Khoom
| Qhov Kev Ntsuam Xyuas | Qib 1: Tus Khub Ua Lag Luam Zoo | Qib 2: Tus Muag Khoom |
| Kev Txhawb Nqa Txog Kev Txawj Ntse | Cov engineers hauv tsev thiab kev tsim kho qhov loj me. | Kev txhawb nqa email xwb; cov khoom "tawm ntawm lub txee" xwb. |
| Kev Tswj Xyuas Zoo | Kev saib xyuas tiag tiag nrog daim ntawv pov thawj ISO 9001 & UL. | Tsuas yog kev sim ua pawg xwb; cov ntaub ntawv tsis sib xws. |
| Kev Muaj Peev Xwm Tshawb Fawb & Kev Txhim Kho | Kev loj hlob nquag ntawm High-Modulus (HM fibers). | Tsuas yog muag cov iav E-iav txheem xwb. |
| Ntim Khoom | Cov ntaub qhwv tiv thaiv UV; cov pallets tiv thaiv dej noo. | Yas qhwv yooj yim; yooj yim rau dej nkag. |
| Kev Ua Raws Cai ESG | Cov pa roj carbon uas pom tseeb thiab kev siv cov khib nyiab rov qab ua dua tshiab. | Tsis muaj kev tshaj tawm txog ib puag ncig. |
| Kev Thauj Khoom | Kev taug qab sib xyaw ua ke thiab ntau qhov chaw nres nkoj xa khoom xaiv. | Tsuas yog Ex-works (EXW); kev txhawb nqa kev xa khoom tsawg. |
4. Kev Tswj Xyuas Zoo thiab Kev Tshawb Xyuas Tau Zoo
Hauv cov lag luam xws li aerospace lossis infrastructure,kev taug qab tauyog tsis sib tham tau. Txhua lub bobbin ntawmiav fiberkev mus ncigyuav tsum taug qab mus rau lub cub tawg tshwj xeeb, cov khoom siv raw, thiab lub sijhawm ua haujlwm uas nws tau tsim tawm.
Cov Ntawv Pov Thawj:Xyuas kom tseeb tias lawv tuavISO 9001: 2015, thiab yog tias koj nyob hauv thaj chaw dej hiav txwv lossis cua, nrhiavDNV-GL los yog Lloyd's Registercov ntawv pov thawj.
Cov Chaw Kuaj Mob:Ib tus neeg muag khoom sab saum toj yuav muaj ib lub chaw kuaj mob hauv tsev los ntsuas lub zog tensile, cov dej noo, thiab kev poob hluav taws xob (LOI) ua ntej ib lub pallet tawm hauv lub tsev rau khoom.
5. Kev Ntim Khoom Zoo Tshaj Plaws thiab Kev Tiv Thaiv Dej Ntxias
Fiberglassua ntej nws raug ua tiav, nws rhiab heev rau ib puag ncig. Yog tias lub bobbin nqus cov dej noo thaum lub sijhawm thauj mus los hauv hiav txwv, cov tshuaj lom neeg ntawm qhov loj me tuaj yeem lwj, ua rau kev sib txuas tsis zoo.
Tus Txheej Txheem:Nrhiav cov neeg muag khoom uas sivkev ntim khoom ntsugnrog rau kev tiv thaiv lub bobbin ib leeg, cov khoom siv ntsws ua haujlwm hnyav, thiab cov pob desiccant.
Cov Lus Qhia Txog Kev Khaws Cia:Soj ntsuam seb tus neeg muag khoom puas muab cov lus qhia meej txog qhov kub thiab txias thiab av noo kom ntseeg tau tias lub sijhawm khaws cia yog 6-12 lub hlis.fiberglasskev mus ncig yog tswj hwm.
6. ESG thiab Kev Ruaj Ntseg Ib puag ncig
Raws li cov cai thoob ntiaj teb zoo liEU lub Txheej Txheem Kho Kom Zoo Dua ntawm Ciam Teb Carbon (CBAM)thaum muaj txiaj ntsig, daim ntawv pov thawj "ntsuab" ntawm koj tus neeg muag khoom yuav cuam tshuam rau koj cov nyiaj tau los.
Kev Siv Hluav Taws Xob Zoo:Puas yog cov chaw tsim khoom siv cov roj oxygen hauv lawv cov cub tawg kom txo CO2?
Kev Tswj Xyuas Pov Tseg:Cov neeg muag khoom siab dua rov ua dua lawv cov khib nyiab iav mus ua lwm yam khoom siv hauv kev tsim kho, pab koj ua tiav koj lub hom phiaj kev ruaj khov ntawm lub tuam txhab.
7. Kev Tshawb Fawb thiab Kev Txhim Kho thiab Kev Kho Kom Haum
Kev lag luam composites tab tom txav mus rau "kev tshwj xeeb." Txawm nws yogalkali-resistant (AR) iavrau cov pob zeb ua los yogkev siv zog siabrau cov hlab ntsha siab, koj xav tau tus neeg muag khoom uas tuaj yeem tsim kho tshiab.
Kev Ntsuas Kev Kho Kom Haum:Nug tus neeg muag khoom:Koj puas tuaj yeem kho qhov txoj kab uas hla ntawm 13μm txog 17μm rau peb lub pultrusion tuag tshwj xeeb?Ib tus neeg tsim khoom tiag tiag yuav koom nrog kev sib tham txog kev siv tshuab; ib tus tub luam yuav qhia rau koj tias lawv tsuas muaj ib qho loj xwb.
Xaus Lus: Tus nqi "Zais cia" ntawm kev roving pheej yig
Thaum xaiv ib qhofiberglass roving neeg muag khoom, tus nqi ntawm daim ntawv them nqi tsuas yog 20% ntawm zaj dab neeg xwb. 80% seem yog pom nyob rau hauv kev ua haujlwm zoo ntawm kev tsim khoom, lub neej ntev ntawm cov khoom, thiab kev txhawb nqa kev siv tshuab. Los ntawm kev tshuaj xyuas koj cov neeg koom tes nrog rau xya yam no, koj xyuas kom meej tias koj cov kab tsim khoom tseem tsis tau cuam tshuam thiab koj cov khoom tseem zoo tshaj plaws hauv ntiaj teb.
At CQDJ, peb txaus siab rau peb tus kheej ua ntau tshaj li ib lub chaw tsim khoom xwb. Peb yog ib tus khub koom tes uas mob siab rau kev tshawb fawb txog kev txhawb zog. Peb cov chaw tsim khoom tau tsim kho kom zoo rau kev tsim khoom ntau thiab sib xws nrog kev tsom mus rau kev tsim khoom ruaj khov.
